Amphenol ACPR-WHT RCA male cable connector

Uusi. Käyttämätön.

SPECIFICATIONS:

Positions: 2

Finish: White

Gender: Male

Contact Plating: Gold

IP Rating: IP40

Current Carrying Capacity: 10A (depending on mating connector)

Termination: Solder

Max Wire Gauge: 14AWG - 2.5mm²

Flammability Rating: UL94V-0

Environmental: Complies with EU RoHS 2 Directive 2011/65/EU

Typical Contact Resistance: < 10mΩ (Depends on mating connector)

Insulation Resistance: < 2GΩ / >10³ Meg Ω after Damp Heat Test

Operating Temperature: -25°C to + 75°C (-13°F to 167°F)

Insertion and Withdrawal Force: > 10N - < 30N

Cable OD Range: 3mm to 7mm (0.11" to 0.275")

Mating Cycles: 500

Housing Material: Diecast Zinc Alloy EZDA No.3

Application(s): Audio & Lighting
